| Operating Voltage | Automatic reclosing | AC175-240V
AC100-240V | Access AC voltage range: AC90-264V 50-60Hz |
| Device Interface | Network transmission | LC/SC fiber port | 2*100/1000M SFP fiber ports (Optional LC / SC interface) |
| Gigabit RJ45 port | 8*10/100/1000Base-X RJ45 ports |
| Console port | 1set Ethernet switch console configuration interface |
| | POE power supply | Port 1-7 support IEEE802.3af/at POE output |
| DC48V power interface | 1 set single output 250W / 48V DC power supply |
| DC12V power interface | 1 set 3-port output 90W / 12V DC power supply, 12V / 2A |
| AC24V power interface | 1 set single output 60W / 24V AC power supply |
| AC220V power interface | 5 hole AC power socket |
| Data control | RS485 interface | 1 set RS485 communication interface |
| RS232 interface | 1 set RS232 communication interface |
| Switch output | 1 set switch output (Connect the alarm circuit, alarm indicator, etc.) |
| Switch input | 2 set switch input (Box door switch, water leak detection) |
| Protective Function | Lightning protection | Network lightning protection | 6-port gigabit network lightning protection |
| 40KA anti-surge protection (SPD) | 40KA AC surge protector |
| Automatic reclosing | Short circuit protection | In case of short-circuit fault, the power-off action time ≤0.1S |
| Electric leakage protection | Electric Leakage current> 30mA, power-off action time≤0.1S |
| Over current / overload protection | Power-off protection when the current is greater than 1.15 times the rated current and greater than 30S or the instantaneous
current is greater than 3 times the rated current |
| Over voltage protection | Power-off protection when the supply voltage is higher than the rated upper limit working voltage + 5V |
| Under voltage protection | Power-off protection when the supply voltage is higher than the rated lower limit working voltage -5V |
| Detection and protection before closing | Failure to restart before closing |
Operation and Maintenance | Data control | Main control board parameters | Flash:4GByte
DDR: 512MByte
CPU: ARM 600MHz |
| Unauthorized unpacking monitoring alarm and video | Illegal unpacking alarm, video recording, and upload. |
| Power failure alarm | DC12V power failure alarm
AC220V mains power failure alarm |
| Fan status monitoring alarm | Fan failure alarm
Fan speed control |
| Temperature detection alarm | Alarm temperature setting,
Above the upper-temp limit, start the fan to dissipate heat;
Less than the lower temp limit, start the chassis heating (The heating module needs to be purchased separately) |
| Water leak detection alarm | Chassis flooding alarm |
| Power monitoring alarm | Real-time alarm for mains over-voltage, under-voltage, lightning strike,short circuit fault |
| Lightning protection frequency monitoring | Count lightning strike times to protect equipment installation and maintenance in advance |
| Power consumption statistics | Real-time display of chassis voltage, current, power |
| Output voltage / current control and monitoring alarm | DC12V output control and alarm
AC24V output control and alarm
AC220V output control and alarm
PoE power output control and alarm |
| System information display screen | Company LOGO
Local management IP address
Query / display the local I / O port status information
Query / display the information of local voltage and current consumption. |
| SMS alarm | The platform sends an alarm message SMS to the mobile phone of the operation and maintenance personnel |
| Network transmission | PoE output network management | Delay start of power supply
Scheduling of PoE operation and time
PoE port real-time power viewing,
PoE port power priority configuration
PoE output power allocation, off& af &at |
| PoE switch network management configuration | DHCP Serve, IGMP multicast
Port mirroring, Port rate setting
Network VLAN division
Link aggregation, QoS configuration
Network storm suppression
MAC + VLAN + IP + port binding
IPV4 / IPV6 dual stack protocol
802.1X access control, 802.3X flow control
ERPS and spanning tree ring network networking, etc. |
| Internet self-healing (Network watchdog) | Network traffic monitoring, offline recovery, downtime recovery, and storm recovery. |
| Network monitoring alarm | Network port dropped alarm
Optical port dropped alarm |
| Device connection topology and status monitoring alarm | intelligent box connection topology
Rename device name
Custom topology design |
| Expansion Module | Data control | 4G wireless transmission | 4G wireless communication function expansion and control |
| Intelligent box heating | The automatic heating system is suitable for long-term low-temperature environment operation |
| GPS positioning | Positioning accuracy ± 0.5 meters |
| Local information storage | Specify or select local system information backup, local storage, provide accurate operation and maintenance information records |
| Chassis repair lights | LDE Light when the box door is opened, providing lighting for smart box installation and maintenance. |
| Chassis Protection | Case shell | Chassis protection level | IP55 |
| Fan | 3200RPM |
| Power supply air switch | AC220V/16A air switch |
| Dimension | H*W*T:540x440x240mm |
| Chassis material | 1.8mm galvanized steel sheet |
| Insect net | The ventilation holes are covered with insect nets to ensure the interior of the box is clear |
